Set of equipment

1. WS1.5CE meter control valve assy (VP15CEDTH)

• WS1.5PCE control valve
• Meter assembly
• Top stack distributor, 50 mm riser
• Power supply
• Injector
• DLFC
• Funnel
• Valve instruction manual, Instruction manual

2. Pressure tank assembly

• Pressure tank 24x72, 4˝
• Riser DN 50 mm
• Lateral bottom stack distributor

3. Brine tank assembly

• Brine tank 30x50, 560 L
• Brine well assembly (brine valve, overflow set)
• Brine grid

4. Resin

• Volume resin: 300 liters
• Type resin: PC002 polydisperse cation exchange resin

CE CONTROL VALVE KEY FEATURES

• Regeneration control by water volume: delayed regen, immediate, both
• Possibility to change the cycle of regeneration stages and their time range
• Multilanguage menu: English, German, French, Ukrainian
• Different setting modes are available:

1. double valve twin or duplex configurations
2. multi-system mode, up to 8 system to the system controller
3. 2 external devices can be connected simultaneously

SPECIFICATIONS

• Maximum service flow rate*: 10.2 m³/h
• Quantity of resin: 300 L
• Volume capacity**: 60 m³
• Usage of salt per regeneration: 30.0 - 48.0 kg
• Usage of water per regeneration: 2.1 - 3.0 m³
• Duration of regeneration: 80 - 120 minutes
• Operating pressure: 2 - 6 bar
• Inlet, outlet: 1.5″
• Drain: 1″
• Brine line: ½˝
• Volume of pressure tank: 450 L
• Dome volume: 46 L
• Volume of brine tank: 560 L
• Dry system weight: 60 kg
• Electrical requirements: 230 V, 50 Hz
• Electrical power: 30 W
• Operating temperature: +4...+30 °C

*  At a hardness of 250 ppm CaCO₃, the salt dose for regeneration is 100 g/L

** With a linear filtration rate of 35 m/h

ACCESSORIES*

• V3009 WS1 Auxiliary Microswitch Assembly
• V3034 Water Specialist 1.5” Plastic Motorized Alternating Valve
• V3035 Water Specialist 1.5” Plastic No Hard Water Bypass Valve
• V4430-02 WS15P fitting assembly QC to BSPT
• V4430-03 WS15P fitting assembly QC to QC

*  Not included in the basic set. Can installed as additional equipment
