Dimensions
Image Size
DIMENSIONS, H×W×D:
248 x 70 x 28
mm
Filter weight
1000
kg
All media (1)
Dimensions
CXRL INOX cold water washable cartridge is designed to protect boilers, washing machines, dishwashers by filtering sand, scale, rust.
Versatile industrial use includes protecting water pumps, irrigation systems, car wash services, filtration of hot water from thermal power plants.
Resistant to extreme washings and still be reused thanks to SS net
Hot water treatment up to 60 °C
Uniform flow and low pressure drop due to cylindrical shape
High pressure resistance thanks to the honeycomb structure
Complies with DM25 standards (ITALY)
Show More Features
Size
2.5" × 10"
Recommended flow rate
8
L/min
Maximum working temperature
4 - 60
°C
Filtration rating
60
micron
Product
Image Size
DIMENSIONS, H×W×D:
248 x 70 x 28
mm
Filter weight
1000
kg
Technical specifications
- Model - CXRL
- Filtration - Sediments
- Filtering medium - Stainless steel AISI 304
- Inter core - Reinforced Polypropylene
- Valves - Reinforced Polypropylene
- Gasket - Elastomer
- Connection - DOE
- Working temperature - From 4°C (39°F) to 60°C (140°F)
- Cartridge type - Washable
- Maintenance - Quarterly
- Duration - 24 months
- Size - 9” ¾
- Flow rate, l/h - 3 500
- Filtration rating, µ - 60
