Set of equipment

1. CE 1" valve assembly (V1CEDM):

• CE 1" control valve
• Top stack distributor, 11 segments
• Connection kit 1''
• Power supply
• Injector, DLFC - for Ecomix and cation exchange resin
• Funnel
• Valve instruction manual

2. Pressure tank assembly

• Motorized Pressure tank 10x54, 2.5"
• Riser
• Bottom stack distributor

3. Brine tank

• Brine tank 15x17x36, 125 L
• Brine well assembly (brine valve, overflow set)

CE CONTROL VALVE KEY FEATURES

• ‍Regeneration control by water volume: delayed regen., immediate, both
• Possibility to change the cycle of regeneration stages and their time range
• Multilanguage menu: English, German, French, Ukrainian
• Different setting modes are available:

          - Twin or duplex configurations

          - Up to 6 systems in the system controller

          - 2 external devices can simultaneously be connected

SPECIFICATIONS

• Water flow rate*

          - Service (pressure drop 1 bar): 6.12 m³/h

          - Backwash (pressure drop 1.7 bar): 6.12 m³/h

• Inlet, outlet: G 1″
• Drain: G 1″
• Brine line: G 3/8″
• Operating pressure: 2-6 bar
• Operating temperature: +4...+30 °C
• Electrical requirements: 230 V, 50 Hz
• Electrical power: 30 W
• Volume of pressure tank: 63 L
• Volume of brine tank: 125 L
• The volume of the rounded side: 2.5 L
• Dry system weight: 15 kg

RECOMMENDED MEDIA VOLUME

• Ecomix Type C filter media: 37 L
• Ecomix Type A filter media: 37 L
• Ecomix Type P filter media: 37 L
• HCRS-S Strong acid cation exchange resin: 37 L
• PC002 Strong acid cation exchange resin: 37 L

The volume of filter material depends on its characteristics. TDS on filter materials can be found on the official website www.ecosoft.com

ACCESSORIES**

• V3006 WS1 Bypass Assembly
• V3009 WS1 Auxiliary Microswitch Assembly
• V3070FM Bypass shut-off valve during regeneration (no-Bypass valve) for 1" and 1.25" systems
• V3069MM-01 Water Specialist 1” & 1.25” Motorized Alternating Valve
• V3191-01 WS1 Bypass Vertical Adapter Assy

** Not included in the basic set. Can be installed as additional equipment.
