Set of equipment

1. TC 1" valve assembly (V1TCBTZ):

• TC 1" control valve
• Top stack distributor, 11 segments
• Connection kit 1''
• Power supply
• DLFC
• Funnel
• Valve instruction manual

2. Pressure tank assembly

• Pressure tank 13x54, 2.5"
• Riser
• Bottom stack distributor

3. Brine tank

TC CONTROL VALVE KEY FEATURES

• Service flow rate of 27 gpm, backwash 27 gpm
• Double backwash feature offers optimum regeneration, cleaning ability and efficiency
• 10 selectable pre-programmed regeneration cycles
• Days between regeneration feature: 1–99 days standard; 7-day optional

SPECIFICATIONS

• Water flow rate*

          - Service (pressure drop 1 bar): 6.13 m³/h

          - Backwash (pressure drop 1.7 bar): 6.13 m³/h

• Inlet, outlet: G 1″
• Drine: G 1″
• Operating pressure: 2-6 bar
• Operating temperature: +4...+30 ^oC
• Electrical requirements: 230 V, 50 Hz
• Electrical power: 30 W
• Volume of pressure tank: 105 L
• The volume of the rounded side: 6.0 L
• Dry system weight: 16 kg

RECOMMENDED MEDIA VOLUME

• Granular activated carbon Centaur 12x40: 30 kg
• Activated Carbon Filtrasorb 300: 50 kg
• Filter-AG filter media: 56.6 kg
• Filter-AG PLUS Filter media: 56.6 kg
• Calcite filter media 16x40: 31.2 kg

The volume of filter material depends on its characteristics. TDS on filter materials can be found on the official website www.ecosoft.com

ACCESSORIES**

• V3006 WS1 Bypass Assembly
• V3009 WS1 Auxiliary Microswitch Assembly
• V3191-01 WS1 Bypass Vertical Adapter Assy

** Not included in the basic set. Can be installed as additional equipment.
